An improved MK-5 Suit to 2024 requirements
EOD Suit PCS-2
PCS-2 Bomb Suits deliver solutions for EOD and IEDD operators during Reconnaissance, IED Manipulation and Render safe procedures. It provides a balance of high level protection with ergonomic considerations. The helmet incorporates air circulation a quick release mechanism allows egress out of the suit very easy and quick. It not only protects the human body from fragments, but also reduces blast overpressure generated in an explosion. With the ECS-03 cooling system, it reduces fatigue during hot weather.
- Comfortable yet with V50 protection at chest is above 2000 m/s
- Ventilating system prevent the visor from fogging.
- Weakens the shock overpressure.
- Removable enhanced plates.
- Tested with grain 17 fragment simulator for V50 as per NATO standards.
Specifications
Specifications
Bullet proof Mask | V50 | 744 m/sec |
Thickness | 22.4mm | |
Weight | 1032g | |
Material | Organic transparent composite | |
Bulletproof Helmet | V50 | 780 m/sec |
Size | 361×273×262mm | |
Protective Area | 0.25m2 | |
Weight | 4104g | |
Material | Kevlar composites laminated | |
Front of smock (Main body of smock) | V50 | 654m/s |
Size | 580×520mm | |
Weight | 1486 g | |
Material | 34-layer woven fabric (Aramid fiber) | |
Blast plate +The front of smock | V50 | >2022m/s |
Throat Plate Dimension | 270×160×19.7mm | |
Throat Plate Weight | 1313 g | |
Abdominal Plate Dimension | 330×260×19.4mm | |
Abdominal Plate Weight | 2058 g | |
Arm (Right Arm, Left Arm) | V50 | 531m/s |
Size | 500×520 mm | |
Weight | 1486 g | |
Material | 25-layer woven fabric (Aramid fiber) | |
Back of thigh and calf (Left and Right Thigh, Left and Right Shin) | V50 | 492m/s |
Size | 530×270mm | |
Weight | 529g | |
Material | 21-layer woven fabric (Aramid fiber) | |
Front of shin (Left and Right Outer) | V50 | 593m/s |
Size | 460×270mm | |
Weight | 632 g | |
Material | 30-layer woven fabric (Aramid fiber) | |
Suit Total Weight | 32.7 kg | |
Power supply | 12V battery | |
Cooling fan | 200 liters/min, adjustable speed |
